NAAC Re-accredited with grade
Intake : 20
View Syllabus of M.Voc. in Printing & Packing TechnologyAs there was no institute in Marathwada region of this educational stream, the thought was it will get great response from the industry. The expectations came to fulfillment when all first year students of Bachelor of Printing Technology & Graphic Arts (BPT&GA) and Advanced Diploma in Printing Technology & Graphic Arts (ADPT&GA) were successfully placed in the industry.
Intake : 20
View Syllabus of ADPT&GA( Advanced Diploma in Printing Technology & Graphic Arts )Year -2011| Name | Specialization |
|---|---|
|
- |
| Sr. No. | Name of the Instrument | Purpose |
|---|---|---|
| 1. |
Electronic GSM Tester - Direct Display of GSM on Scale - 2 sample size measurement – 1020 and 2020 cms - Solid metal base with aluminium body - Factory calibrated pendulum assembly - Levelling bolt for zero adjustment of the pendulum - Two cutting templates supplied with the equipment - Direct Display of GSM on LED Screen - 5 Sample size Measurements: 5×5, 10×10, 10×20, 20×20, 25×25 cms - Breeze shield for accurate and air-free weighing - Calibration in 6 Simple steps - Two modes of measurement (GSM and Weighing), Overload protection (Preset) - Accurate Die Cutter and Round Cutter - Conforms to: TAPPI T410om, ASTM D3776/2646-96, ISO 3801 |
To measure weightage of paper. Most paper is bought and sold in accordance with its mass per unit area, so the grammage has great significance both to the consumer and the producer. It defines price and influences physical properties like Bursting Strength, Thickness, and Bulk. |
| 2. |
Puncture Resistance Tester - Five different scales to analyze materials of variable thickness - Easy lever press clamp mechanism - Zero adjustment screw for calibration - Operator protection guard - Tests wide range of materials (thin paper to thick boards) - Augmented weights allow 1300 units of energy Standard Compliance: TAPPI T-803 om-88, IS 4006 (Part II) 1972, IS 2771 (Part II) 1973, ASTM D-781 -68, DIN 53142, SCAN P23 |
Significance: Evaluates puncture resistance of board materials, useful for simulating impacts like box corner puncture. Principle: Measures energy required to puncture board. One unit = 0.265 in. Lb (0.305 cm. kg). Factors include tearing and displacement energy. |
| 3. |
Rub Proofness Tester - State-of-the-art design - Stainless Steel body - Compact and silent operation - Analog click counter - Minimal maintenance - Blower removes loose dust/print - LED display for rub count - Programmable rub cycles - Time-bound testing capability |
|
| 4. |
Cobb Sizing Tester - Tests paper, board, waterproof board - Height graduations: 10, 25, 100 mm (as per TAPPI T 441) - Adjustable clamp pressure - Stainless steel roller and aluminum block |
Significance: Measures water absorptiveness. Useful for checking sizing, porosity, and resistance to liquids like water or oil. |
| 5. |
Electronic Moisture Tester - Handy, pocket-sized - Automatic setting - No external electrodes required - Suitable for wood, gypsum, plaster |
|
| 6. |
Elmendorf Tear Tester - Models: Electronic, Heavy Duty - Digital pendulum balancing - Configurable display - One-touch software - RS-232 output - Quick capacity change - Pneumatic clamping and release |
Standard Impact Head: Radius: 0.5 in (12.7 mm) Diameter: 0.75 in (19.0 mm) O-Ring Clamp ID: 89 mm Sample Size: 5×5 in (127×127 mm), 5.25 in dia (133.35 mm) Air Clamp Min: 60 PSI Pendulum Capacities: 200–6400 grams |
| 7. |
Integrated Hardness Tester - USB test direction communication - 270 test memory - Limit setting - Auto shut-off - Backlight for dark use - Battery status display - Uses AAA 1.5V battery - Integrated calibration - Model: TH 170 (with D impact device) |
|
| 8. |
Digital Microscope - Handheld and portable - Captures video and photos - Magnifications: 5x–500x - Software downloadable - Polarization feature - Measurement facility - Up to 5MP resolution - Interfaces with computer/TV - Wide variety of stands - Common Uses: Corrosion check, Car tire (200x), Steel wire cloth |
-No information available
Signed a Memorandum of Understanding between Beijing Institute of Graphic Communication, Beijing, China and Dr. Babasaheb Ambedkar Marathwada University under the aegis of All India Federation of Master Printers, Delhi on 12 May, 2016.
